When choosing a home energy storage system, the capacity matching of lithium iron phosphate batteries and inverters directly affects the user experience and economy. A comprehensive consideration should be made from three aspects: power demand, equipment characteristics and scene adaptation to ensure the efficient and stable operation of the system.

Accurate calculation of electricity demand is the prerequisite. First, calculate the power of the core household electrical appliances, such as the refrigerator (150W), lighting (100W), router (20W), etc. Then, add the simultaneous usage coefficient to obtain the total power. Based on a daily power outage of 4 hours, the basic power consumption is (150+100+20) W×4h=1080Wh. Considering 20% redundancy and battery discharge depth (usually 80%), the battery capacity needs to reach 1080Wh÷80%=1350Wh, which is 1.35kWh. If it is necessary to support high-power devices such as air conditioners (1.5kW), the instantaneous power peak (approximately 3kW) should be calculated separately.

2. Scientifically match battery capacity with performance. When choosing the capacity of llithium iron phosphate batteries  attention should be paid to energy density and cycle life. For household use, it is recommended to give priority to 2-5kWh modular battery packs for convenient expansion in the future. For instance, if the daily power consumption is 2kWh, a 3kWh battery can meet the standby demand for 1.5 days, while also avoiding the frequent charging and discharging of small-capacity batteries, which could lead to a shortened lifespan. Note that the battery voltage needs to match the input specification of the inverter. Commonly, 48V systems have better compatibility and can reduce line losses.

3. The inverter capacity should have sufficient safety margin. The power of the inverter should be greater than the total power of all the devices working simultaneously, and it is usually configured at 1.2 to 1.5 times. If the total power is 2kW, the inverter should be selected as a 2.5-3kW model. Pure sine wave inverters have a wider range of adaptability, especially being more friendly to inductive loads such as air conditioners and refrigerators. In addition, grid-connected or off-grid inverters should be selected based on the installation scenario. Grid-connected systems need to have anti-islanding protection functions, while off-grid systems should be matched with a battery management system (BMS) to achieve charge and discharge control.

4. Comprehensive scene optimization configuration plan. In the rainy southern regions, 2kW photovoltaic panels +3kWh batteries +3kW inverters can be combined to achieve basic self-sufficiency. In cold northern regions, it is recommended to increase the battery capacity to 5kWh and choose lithium iron phosphate batteries with better low-temperature performance. In daily use, maintaining the battery power within the range of 20% to 80% can extend the service life. When configuring the system, an intelligent controller can be added to achieve automatic charging and discharging management, thereby enhancing the overall operational efficiency.

Only by scientifically calculating the power load, rationally matching the parameters of lithium iron phosphate batteries  and inverters, and optimizing the configuration in combination with the regional climate characteristics can a safe, economical and efficient household energy storage system be created, which not only meets the emergency power supply needs but also achieves long-term stable operation.
